AluDeck

Mounting system for terraces with pavers and boards on a substructure of aluminum joists

terrace joist

terrace tiles

wooden decking

wpc decking boards

ALUDECK features

AluDeck 1

The tiles are supported along their entire length

AluDeck 2

Faster installation

AluDeck 3

The terrace is more stable

AluDeck 4

A complete system, including accessories

Packshots adec ajr view 4

ADEC-AJR2000-(1) Joist soundproofing tape AluDeck 2000 mm

Packshots adec adj25x45x4000 view 4

ADEC-ADJ25X45X2000-(1) AluDeck 25×45×2000

Packshots adec adj40x45x4000 view 4

ADEC-ADJ40X45X2000-(1) AluDeck 40×45×2000

Alu Click Adapter

ADEC-ACA-(200(25x8)) AluDeck click adapter - STANDARD / CLEVER LEVEL

Packshots adec apk3 view 4

ADEC-APK3-(500(50x10)) AluDeck sliding cross spacer 3 mm

Packshots adec apk5 view 4

ADEC-APK5-(500(50x10)) AluDeck sliding cross spacer 5 mm

Packshots adec apl3 view 4

ADEC-APL3-(2000(50x40)) AluDeck sliding linear spacer 3 mm

Packshots adec apl5 view 4

ADEC-APL5-(2000(50x40)) AluDeck sliding linear spacer 5 mm

Packshots adec le100 view 4

ADEC-LE100-(85) AluDeck self-levelling head - STANDARD

Packshots adec le145 view 4

ADEC-LE145-(36) AluDeck self-levelling head - MAX / SPIRAL

Packshots adec alc view 4

ADEC-ALC-(50) AluDeck longitudinal joist connector

Packshots adec acc view 4

ADEC-ACC-(50) AluDeck transverse joist connector

ALUDECK pedestals

CLE-025-040-L3-AD-(200) Clever Level 25-40 mm pedestal, 3 mm for tiles & decking

Packshots cle 040 080 l3 ad view 4

CLE-040-080-L3-AD-(120) Clever Level 45-80 mm pedestal, 3 mm for tiles & decking

Packshots cle 080 200 l3 ad view 4

CLE-080-200-L3-AD-(50) Clever Level 80-200 mm pedestal, 3 mm for tiles & decking

Packshots max 045 075 dad view 4

MAX-045-075-DAD-(54) MAX pedestal 45-75 mm with DAD for decking

Packshots max 075 150 dad view 4

MAX-075-150-DAD-(36) MAX pedestal 75-150 mm with DAD for decking

Packshots max 150 350 dad view 4

MAX-150-350-DAD-(18) MAX pedestal 150-350 mm with DAD for decking

Packshots spi 010 017 dad view 4

SPI-010-017-DAD-(125) SPIRAL pedestal 10-17 mm with DAD for decking

Packshots spi 017 030 dad view 4

SPI-017-030-DAD-(90) SPIRAL pedestal 17-30 mm with DAD for decking

Packshots spi 030 050 dad view 4

SPI-030-050-DAD-(100) SPIRAL pedestal 30-50 mm with DAD for decking

Packshots spi 050 070 dad view 4

SPI-050-070-DAD-(70) SPIRAL pedestal 50-70 mm with DAD for decking

Packshots spi 070 090 dad view 4

SPI-070-090-DAD-(50) SPIRAL pedestal 70-90 mm with DAD for decking

Packshots sta 030 045 ad view 4

STA-030-045-AD-(100) Adjustable pedestal STANDARD 30–45 mm with AD

Packshots sta 045 070 ad view 4

STA-045-070-AD-(70) Adjustable pedestal STANDARD 45-70 mm with AD

Packshots sta 070 120 ad view 4

STA-070-120-AD-(50) Adjustable pedestal STANDARD 70-120 mm with AD

Packshots sta 120 220 ad view 4

STA-120-220-AD-(36) Adjustable pedestal STANDARD 120-220 mm with AD

Packshots rap s 15 35 view 4

RAP-S-15-35-(100) RAPTOR S pedestal 15–35 mm for decking

Packshots rap m 35 65 view 4

RAP-M-35-65-(100) RAPTOR M pedestal 35-65 mm for decking

Packshots rap l 65 95 view 4

RAP-L-65-95-(100) RAPTOR L pedestal 65-95 mm for decking

Packshots rap xl 095 125 view 4

RAP-XL-95-125-(55) RAPTOR XL pedestal 95-125 mm for decking

ALUDECK accessories

Innovative tool-free connection system and "click" frame mounting drastically reduce working time and eliminate the risk of installation errors.

Replacing support points with a stable, linear structure of aluminum joists reduces the risk of paver cracking and eliminates the risk of them shifting.

Integrated rubber tape eliminates vibrations, guaranteeing the highest comfort of terrace use.

EN Brochure AluDeck

AluDeck

Check how the AluDeck system works with both terrace boards and pavers in commercial projects:
